Tamagawa Encoder TS2620N21E11 Original New Tamagawa TS2620N21E11 in Stock

Encoders, at present, have been widely used for factory automations, measurements, office automation devices, medical equipment, aviation and universal fields. From small to high absolution are available to meet all of the requirements.
  • TS2620N21E11
  • Tamagawa
Availability:
Quantity:

Tamagawa Encoder TS2620N21E11 Original New Tamagawa TS2620N21E11 in Stock

Purpose and characteristics of Tamagawa encoder in Japan:

1. Tamagawa Tamagawa encoder has small size, full through-hole, high accuracy, easy installation, low price and high performance design, so Tamagawa encoder has strong anti-interference force.

2. Tamagawa Tamagawa encoder is suitable for precision working environment and automatic industrial control field.

3. Tamagawa Tamagawa encoder is characterized by impact resistance, good vibration resistance, small size, light weight, strong load, etc

Size
15
Model
TS2620N21E11
Type
1X-BRX
Primary
R1-R2(Rotor)
Input voltage
AC7Vrms 10kHz
Transformation ratio [K]
0.5±5%
Electrical error (Accuracy)
±10'Max
Residual voltage
20mVrms Max
Phase shift
0°REF
Input impedance
Zro
70+j100ΩNom
Output impedance
Zso
180+j300ΩNom
Zss
175+j275ΩNom
Allowable rotation speed
10,000min-1{rpm}
Operating temperature range
-55℃~+155℃
Dielectric strength
AC500Vrms1min
Insulation resistance
100MΩMin
Mass
0.065kg Max
Output voltage equation
+type


TS2620N21E11尺寸图
