Cylinder Type Non Flush Sensor M30 Inductive Proximity Sensor LM30-3015PC

Inductive proximity sensor
Used in harsh working environment, it can withstand all kinds of cutting fluids and has the effects of waterproof and oil proof. Protection grade IP67. Installed in metal, flush or non flush.There are various models, and the power supply voltage can be 6-36v/15-36 DC power supply; 380V, 20 ~ 250V, 90 ~ 250V AC power supply, 20 ~ 250V AC and DC power supply. Solid brass, nickel plated shell / plastic shell, inner shell sealed with process polymer.

Model:
LM30-3015PC
Brand:
USYUMO
Download:
LM30.pdf

Availability:

Quantity:



Inquire Add to Basket

LM30-3015PC Cylinder Type Non Flush Sensor M30 Inductive Proximity Sensor

Main Features of proximity switch

1.Compact volume

2.High precision of repeated location

3.Diversified exterior structures

4.Good performance of anti-interference

5.Many output forms

6.High on-off frequency

7.Wide voltage range

8.Dust proof, vibtation proof, water proof and oil proof

9.With short-circuit protection and inverted connecting protection

10.Long service life

接近开关系列选型图

Model	LM30-3015PC
Controloutput	DC 200mA
Detection distance	15mm
Protection grade	IP67
Working environment temperature	-25°C~+75°C
Shell material	Metal
Insulation resistance	50MΩ
Repeated precision	0.05
Standred detected object	30x30x1(A3iron)
DC/AC response frequency	200Hz/25Hz
